Our fastest road bike, stripped back and ready for your vision.
The Teammachine R VAR 0 distils race-winning performance to its essentials, leaving you with a pure platform for your own interpretation. Developed with Red Bull Advanced Technologies, it delivers the same time-saving aerodynamics, sprint-ready stiffness, confident handling, and controlled compliance as the complete Teammachine R.
Finished in a light lacquer, the frameset can be ridden raw or given your dream finish. Call it a pro team of one: a lightweight, uncompromising race platform ready for climbs, cobbles, sprints, and corners alike.
You bring the vision. The speed is already there.
Frame:
Teammachine R 01 | 01 Premium Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | Stealth Dropout Design | Flat Mount Disc | 12 x 142mm Thru-Axle
Fork:
Teammachine R 01 | 01 Premium Carbon | ICS Technology Stealth Cable Routing | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle
Seat
Seatpost:
Teammachine R 01 | 01 Premium Carbon Seatpost | 0mm Offset Size 47-51 and 10mm Offset Size 54-61
Drivetrain
Front Derailleur:
Riveted derailleur hanger for Front Derailleur (2x drivetrain - 44.5mm chainline)
Rear Derailleur:
BMC derailleur hangers: SHIMANO Direct Mount + SHIMANO or SRAM Direct Attachment (standard)
Bottom Bracket:
Press-Fit 86.5mm Road
Brakes
Rotor Size (F/R):
Rotor compatibility: 160mm front | 140mm or 160mm rear
Accessories
In the Box:
Aerocore Bottle Cages | Shimano Direct Mount derailleur hanger | Classic SRAM/Shimano derailleur hanger | High and low ICS top cones, 3x10mm spacers , 2x3mm spacers
Additional Information
Tire Clearance:
30mm measured tire
Weight without Pedals:
1780g | Size 54 as pictured with all accessories
ASTM Classification:
Level 1
System Weight Limit:
110kg
